安規檢測項目及標準

2022-10-20   ?   Orange

安規檢測介紹:

現今國際市場上紛紛提出對出口產品安全性能的要求,歐洲、北美甚至其他亞洲國家針對安規提出了各自不同的標準,出口不同國家如何更好的符合相應的安全標準成為企業目前一大難題。

各國認證項目:

歐洲:CE-LVD、GS、TUV-mark、EMF、KEMA、NEMKO、SEMKO、DEMKO、ENEC、BEAB、GOST、ErP;

亞洲:CCC、CQC、KC、PSE、S-mark、BSMl、PSB、SASO;

北美洲和南美洲:UL/cUL、FDA、ETL/cETL、CEC、cTUVus、Energy Star、CSA/CSAus、NOM、IRAM、UC;

澳大利亞和非洲:SAA、MEPS、SONCAP、SABS;

全球認證標志:CB。


安規檢測項目及標準(圖1)


安規檢測范圍:

1.信息技術設備:IEC/EN/UL60950-1/-21/-22,CSAC22.2 NO.60950-1,AS/NZS60950.1,J60950,K60950,GB4943;

2.音視頻設備:IEC/EN/UL60065,CSA C22.2 NO.60065,AS/NZS60065,J60065,K60065,GB8898;

3.電源類:IEC/EN/UL60950-1,IEC/EN/UL60065,IEC/EN/UL60601,IEC/EN60335-2-29,IEC/EN615581/-2,AS/NZS61558.1/.2.X,UL1310,UL1012,UL697,GB19510,GB8898,GB4943;

4.不間斷電源(UPS):IEC/EN62040-1-1,AS 62040.1.1,UL1778;

5.2類和3類***:UL5085-1/-2/-3,UL1585;

6.電池類:UL2054,UL1642,IEC/EN62133,JIS C 8712/8714,UN38.3;

7.燈具:IEC/EN60598-1/-2-X,AS/NZS60598.1/.2.X,J60598-1/-2-X,K60598-1/-2-X,GB7000.1/.X;

8.固定式燈具:UL1598, IEC/EN60598-2-1,GB7000.201;

9.嵌入式燈具:UL1598,IEC/EN60598-2-2,GB7000.202;

10.便攜式燈具:UL153,IEC/EN60598-2-4,GB7000.204;

11.隧道燈/路燈:UL1598,IEC/EN60598-2-3,GB7000.5;

12.應急照明燈具:UL924,IEC/EN60598-2-22,GB7000.2;

13.投光燈具:UL1598,IEC/EN60598-2-5,GB7000.7;

14.軌道燈:UL1574,UL1598,IEC/EN60598-2-1,GB7000.201;

15.普通照明自鎮流燈(節能燈、射燈、LED球泡燈):UL1993,IEC/EN60968,AS/NZS60968,IEC/EN62031,IEC/EN62560,IEC62471;

16.LED 燈管:UL8750,UL1993,UL1598C,IEC60061,IEC62471,IEC62031,IEC61347-2-13,IEC61195,IEC61199;

17.燈的控制裝置電子鎮流器:IEC/EN61347-1/-2-X,AS/NZS61347.1/.2.X,UL8750,UL935,GB19510.X;

18.LED模塊用交流或直流電子控制裝置:IEC/EN61347-2-13,GB 19510.14;

19.熒光燈用交流電子鎮流器:IEC/EN61347-2-3,GB 19510.4;

20.熒光燈鎮流器:IEC/EN61347-2-8,GB 19510.9;

21.放電燈(熒光燈除外)鎮流器:IEC/EN61347-2-9,GB 19510.10;

22.燈具及燈具系統光生物學安全:EN62471;

23.燈具EMF:EN62493:2010;

24.家用電器:AS/NZS60335.1/.2.X,J60335-1/2-X,K60335-1/2-X,GB4706.1/.X;

25.馬達類食物處理器(攪拌機/榨汁機/碎肉機/切片機):UL982,IEC/EN60335-2-14,GB4706.30;

26.液體加熱器具(咖啡壺/電水壺):UL1082,IEC/EN60335-2-15,GB4706.19;

27.皮膚或毛發護理電器(風筒/卷發器/直發器等):UL859,IEC/EN60335-2-23,GB4706.15;

28.電熱毯、電熱墊和類似柔性加熱電器:UL130,IEC/EN60335-2-17,GB4706.8;

29.紫外和紅外輻射皮膚護理電器:IEC/EN60335-2-27;

30.電池充電器:UL1310,IEC/EN60335-2-29,GB4706.18;

31.房間電熱取暖器:UL1278,IEC/EN60335-2-30,GB4706.23;

32.抽油煙機:UL507,IEC/EN60335-2-31,GB4706.28;

33.電磁灶:IEC/EN60335-2-9,GB4706.29;

34.按摩器:UL1647,IEC/EN60335-2-32,GB4706.10;

35.馬達:UL2111/UL1004,IEC/EN60335-2-34;

36.房間空氣調節器/除濕機:UL484,IEC/EN60335-2-40,GB4706.32;

37.商用電烤架和面包片烘烤器:IEC/EN60335-2-48;

38.空氣清新機/負離子發生器:UL867,IEC/EN60335-2-65,GB4706.45;

39.冷熱飲水機:IEC/EN60335-2-15,GB4706.42;

40.加濕器:UL998,IEC/EN60335-2-98;

41.電熨斗:Ul1005,IEC/EN60335-2-3,GB4706.2;

42.洗碗機:UL749,IEC/EN60335-2-5,GB4706.25;

43.剃須刀,頭發剪和類似裝置烤架,烤箱,多士爐和油炸鍋,電煎鍋:UL1028,IEC/EN60335-2-8,UL1026,IEC/EN60335-2-9,GB4706.14;

44.風扇:UL1083,IEC/EN60335-2-13,GB4706.56;

45.家電EF:UL507,IEC/EN60335-2-80, GB4706.27。

安全測試項目:

1.輸入測試;

2.潮態測試;

3.鋼球沖擊測試;

4.接觸電流試驗;

5.標簽?zāi)途眯詼y試;

6.爬電距離和電氣間隙;

7.跌落測試;

8.電氣強度測試;

9.電容放電測試;

10.工作電壓;

11.應力消減測試;

12.異常測試;

13.限電流電路測試;

14.電源線拉力測試;

15.載重測試;

16.耐熱和耐燃;

17.限功率測試;

18.穩定性測試;

19.直插設備力矩測試;

20.球壓測試;

21.保護接地之阻抗;

22.250N穩定力測試;

23.溫升測試;

24.輻射、毒性和類似危險。

環境可靠性測試標準:

1.環境試驗總則:IEC 60068-1(GB2423.1): General and guidance;

2.冷卻:IEC 60068-2-1:Cold;

3.高溫:IEC 60068-2-2(GB2423.2): Dry heat;

4.沖擊:IEC 60068-2-27: Shock;

5.交變濕熱(12+12小時循環):IEC 60068-2-30(GB2423.4): Damp heat,cyclic (12 h + 12 h cycle);

6.鹽霧,循環(氯化鈉溶液):IEC 60068-2(GB2423.18):Salt mist, cyclic (Sodiumchloride solution);

7.振動(正弦波):IEC 60068-2-6(GB2423.10) Vibration (sinusoidal);

8.錘擊試驗:IEC 60068-2-75(GB2423.55) Hammer tests;

9.防塵防水防護等級試驗:IEC 60529(GB4208)   IP;

10.燈具:LM-79,LM-80,CEC-400-2010-012,F(xiàn)ixtures Eligibility Criteria-Version 4.2,AS/NZS 4782,4783,4934,4879,EC859/2009;

11.電源:CEC-400-2010-012, EC 278/2009, AS/NZS 4665, GB20943;

12.家電:AS/NZS 2040 (Washers),4474 (Refrigerators),2007( Dishwasers),2442( Cloth drayers);

13.音視頻類:Version 5.3 (Television),Version 4.0(Set-top Boxes),AS/NZS62087(Set Top Boxes, Television),EC/642:2009。

中國能效標識:

1.自鎮流熒光燈:GB 19044-2003;

2.高壓鈉燈:GB 19573-2004;

3.家用電磁灶:GB 21456-2008;

4.平板電視機:GB 24850-2010;

5.顯示器:GB 21520-2008;

6.數字電視機接收器:GB 25957-2010;

7.電飯鍋:GB 12021.6-2008;

8.電風扇:GB 12021.9-2008;

9.電動洗衣機:GB 12021.4-2004;

10.儲水式電熱水器:GB 21519-2008;

11.復印機:GB 21521-2008。
